Intrinsically safe gas detector X-Gard with electro-chemical sensor

Product number: 880401
Product information " Intrinsically safe gas detector X-Gard with electro-chemical sensor"
The Gasmaster III system is a stationary measuring instrument for continuous ozone measurement in the vicinity of ozone generators, residual ozone destroyers and ozone treatment plants.

The measuring system consists of:
  • Gasmaster evaluation unit in wall-mounted housing with display (art. no. 880532)
  • Electrochemical detectors X- GARD for ozone (art. no. 880401)

Technical data:
  • Display: 0-1 ppm ozone
  • Electrical output: 4-20 mA or 1-5 VDC
  • Alarm: 2 limit values, red LED ; Local error indication: yellow LED ; Relay contact 5A
  • Digital output: RS485 Modbus
  • Dimensions (LxWxH): 288 x 278 x 110mm
  • Mains connection: 230 VAC, 50-60 Hz

Dimensions

Length 16,5 cm
Width 12 cm, 14 cm

Weight

Weight 650 g

Other attributes

Country of origin GB
Customs tariff number 90268020
