Product information "JUMO hydroTRANS S20 "
JUMO hydro TRANS S20 - Humidity and temperature transmitter with optional wall-mounted CO2 module
Typ: 907042/12-0-17-009/000
- Basic type extension: RH-T-CO2
- Version: Standard
- Measuring range: 0 ... 95 % rH / -10 ... +60°C / 10.000 ppm
- Output: 4 bis 20 mA / 0 bis 10 V combi output configurable
- Extra code: without
- Measuring parameters: Temperature, relative humidity, carbon dioxide (CO2) optional
- Interfaces: USB, RS485, Sigle Pair Ethernet (SPE)
- Robustness
- Easy to install
- Multi-sensor
- Optional plastic sintered filter
The humidity and temperature transducer monitors the quality of the ambient air and can be wall-mounted both indoors and in protected outdoor areas.
Areas of application
- Climate monitoring
- Ventilation systems
- Building management
- Storage rooms
Other attributes
Ausgang | 4...20 mA / 0...10 V (Kombiausgang konfiguriert) |
---|---|
Customs tariff number | 90258040 |
Messbereich (Temperatur & relative Feuchte) | 0...95% rF / -10°C...+60°C |
Messparameter | Kohlenstoffdioxid (CO2), Relative Feuchte, Temperatur |
Downloads:
Electrical safety
Requirements |
DIN EN IEC 61010-1:2020 The device must be supplied with an electrical circuit that meets the requirements for "energy-limited circuits". |
Electric Dating
Device with analogue output
Power supply |
DC 24 V, -33 %/+33 %, SELV, PELV |
Power consumption |
≤ 2,4 W |
Surge Category |
II |
Degree |
2 |
Class |
DIN EN 61140, Class III (Protective extra-low voltage) |
Electrical connection Connection Elements |
Spring clamb |
Connection cable cable cable cross-section Without ferrule With ferrule Stripping length Without ferrule With ferrule Temperature resistance |
AWG 28 bis AWG 14 |
0,2 to 1,5 mm2 |
|
0,25 to 1,5 mm2 |
|
8 mm |
|
10 mm |
|
≥ 80 °C |
Device with RS485
Power supply |
DC 24 V, -58 %/+33 %, SELV, PELV |
Power consumption |
≤ 2,4 W |
Surge Category |
II |
Degree |
2 |
Class |
DIN EN 61140, Class III (Protective extra-low voltage) |
Electrical connection Connection Elements |
Spring clamb |
Connection cable cable cable cross-section Without ferrule With ferrule Stripping length Without ferrule With ferrule Temperature resistance |
AWG 28 to AWG 14 |
0,2 to 1,5 mm2 |
|
0,25 to 1,5 mm2 |
|
8 mm |
|
10 mm |
|
≥ 80 °C |
Device with SPE
Power supply |
DC 18 to 30 V, PELV |
Power consumption |
≤ 100 mA |
Power consumption |
≤ 1,8 W |
Surge Category |
II |
Degree |
2 |
Class |
DIN EN 61140, Class III (Protective extra-low voltage) |
PoDL-Class |
Class 11, IEEE 802.3cg |
PoDL-Classification |
SCCP- oder Forced-Mode |
Electrical connection Connector |
M12-Plug connection |
M12 Connectors |
IEC 63171-5 |
Execution |
2-polig, shielded |
Protection |
IP67 |
Trunk |
IEC 61156-13, IEC 61156-14 |
Execution |
2-adrig, Kupfer, shielded |
Bandwidth |
≥ 20 MHz |
Length |
≤ 500 m (AWG22 bei DC 24 V) |
DC Loop Resistor |
< 59 Ω |
Temperature resistance |
≥ 80 °C |
Inputs
Measuring range
Relative residual moisture
Measuring range With CO2 module |
0 to 100 % RH 0 to 95 % RH |
Accuracy |
|
Typical |
±2,0 % RH |
Max. |
±2,5 % RH |
Measurement Rate |
1 s |
Temperature
Measuring range With CO2 module |
-40 to +80 °C -10 to +60 °C |
Genauigkeit |
|
Typical |
±0,2 °C |
Max. |
±0,4 °C |
Measurement Rate |
1 s |
Carbon dioxide (CO2)
Optional on devices with analog output and RS485, factory on devices with SPE.
Measuring range |
400 to 10000 ppm |
Accuracy Reference Conditions Ambient temperature Air Pressure Humidity Measuring range |
±(50 ppm + 5 % from the measured value)
25 °C 1013 hPa 50 % RH 400 to 1 000 ppm |
Measurement Rate |
30 s |
Exits
Device with analogue output
Power Output
Signal Range |
4 to 20 mA |
Output Signal Limits |
0 to 22 mA |
Accuracy |
≤ ±0,05 % related to end of signal range (20 mA) |
Temperature |
±50 ppm/K |
Burden Influence |
≤ ±0,02 % pro 100 Ω |
Burde |
≤ 500 Ω |
Voltage output
Signal Range |
0 to 10 V |
Output Signal Limits |
0 to 11 V |
Accuracy |
≤ ±0,05 % related to end of signal range (10 V) |
Temperature |
50 ppm/K |
Load Influence |
≤ ±15 mV |
Last |
≥ 10 kΩ |
Interfaces
USB
Function |
Übertragen von Konfigurationsdaten und Geräteinformationen |
Communication |
Via device and setup software |
Transmission standard |
USB 2.0 |
Plug Type |
Micro-B |
Power |
≤ 500 mA |
Cable length |
≤ 5 m |
RS485
Function |
Übertragen von Prozessdaten, Konfigurationsdaten und Geräteinformationen |
Communication |
Über Modbus-Master |
Galvanic isolation |
Funktional |
Data transmission |
Seriell |
Transport |
Modbus RTU |
Data format |
8-1-nonea 8-1-odd 8-1-straight 8-2-none |
Data rate |
9600 Baud 19200 Baud 38400 Bauda 57600 Baud 115200 Baud |
Minimum response time |
0 to 500 ms |
Device Address |
1 to 254 |
a Default setting
SPE
Function |
Transmission of process data, configuration data and device information, power supply via PoDL |
Communication |
Via end device and JUMO Cloud, Modbus-Master |
SPE-Standard |
10BASE-T1L |
Transmission protocol |
Modbus TCP, Integrated JUMO Cloud-Gateway |
Data rate |
10 Mbit/s |
Display
Typ |
TFT-Display |
Size Display Screen diagonal |
35,04 mm × 28,03 mm 1,77″ |
Resolution |
128 × 160 px RGB |
Brightness |
11 Tiers (configurable)) |
Environmental impact
Permissible ambient temperature With CO2-Modul With Display |
-40 to +80 °C -10 to +60 °C -20 to +60 °C |
Permissible storage teperature With CO2- Modul With Display |
-40 to +80 °C -30 to +70 °C -30 to +60 °C |
Protection |
DIN EN 60529 IP65 |
Installation height max. |
5300 m above NN |
Climatic conditions Climat class Relative humidity |
DIN EN IEC 60721-3-3 3K24 ≤ 100 % (95 % with CO2-Modul), non-condensing |
Electromagnetic compatibility (EMC)) Emission Stability |
DIN EN IEC 61326-2-3:2022 Klasse Ba Industrieanforderung |
Vibration deflection Acceleration |
DIN EN 60068-2-6 0,15 mm from 10 to 58,1 Hz 20 m/s2 from 58,1 to 150 Hz |
Shockb Peak Acceleration Shock Duration |
DIN EN 60068-2-27 150 m/s2 11 ms |
a The product is suitable for industrial use as well as for household and small businesses.
b The CO2 module is sensitive to vibrations. In the event of vibrations, the measurement result may change due to the design.
Mechanical Properties
Materials Case Displaycover |
PC PMMA |
Weight |
Ca. 200 g |
