The calibration box is used for the calibration of Modbus sensors. The wires from the sensors are connected to the terminal block on the front of the box and the Box is connected to a computer via a USB interface.Advantages:Simple and safe calibration of the Modbus sensors
Head transmitter:
Modbus 12-24 VDC
|
Tee:
1" flow cell with 3/4" inner thread NPT
|
measuring range:
0.1-500 μS/cm
The conductivity sensor consists of a 3 meter connection cable, a Modbus head transmitter, and the conductivity sensor. Due to the design of the sensor assembly, only the sensor needs to be replaced. All other components of this system can be used continuously. For an optimal process integration the NeoTec sensor is delivered with a fitting T-piece.
Advantages:Preconfigured for NeoTecMaster®
Modular design
Industry standard
conserves resources
Head transmitter:
Modbus 12-24 VDC
|
Tee:
1" flow cell with 3/4" inner thread NPT
|
measuring range:
-2000mV to +2000mV
The modular ORP measuring package consists of a 3 m connection cable, a Modbus head transmitter, the sensor holder and the ORP flat-head electrode. Due to the construction of the sensor only the ORP electrode has to be replaced. All other components of this system can be used continuously. For an optimal process integration the NeoTec Sensor is delivered with a fitting T-piece.
Advantages:preconfigured for NeoTecMaster®
modular design
industry standard
resource friendly
The modular pH measuring package consists of a 3 m connection cable, a Modbus head transmitter, the sensor holder and the flat-head pH electrode. Due to the design of the sensor assembly, only the pH electrode needs to be replaced. All other components of this system can be used continuously. For optimal process integration, the NeoTec Sensor is supplied with a suitable T-piece.Advantages:preconfigured for NeoTecMaster®
modular design
industry standard
resource friendly
Which sensor is used?:
Conductivity cell constant c = 1
Module for manufacturer-independent integration of pH, ORP and conductivity standard sensors (PT1000 based), which do not have an integrated signal converter on site. Integration of existing/existing sensors into the NeoTecMaster® concept via 4-20 mA signal.Advantages:accommodates all pH, ORP and conductivity standard electrodes industry standard
allows the use of existing sensors
Module for manufacturer-independent integration of pH, ORP and conductivity standard sensors (PT1000 based), which do not have an integrated signal converter on site. Integration of existing/existing sensors into the NeoTecMaster® concept via Modbus signal.Advantages:
accommodates all pH, ORP and conductivity standard electrodes
industry standard
allows the use of existing sensors
The use of the NeoTec Slave 4-20 mA allows to process up to six external 4-20 mA measuring
signals. Via the additional four outputs which are defined as 4x 0-10V or 2x 0-10V + 2x 4-20mA, the data can be transferred process-specific to downstream components.Advantages:inversion of the input signals on the assigned outputs possible
(e.g. for concentration-dependent pump control) compact design for top hat rail mounting when using several modules, only one power supply is necessary addition of a further module for application integration possible
By using these NeoTec Slave relay modules, potential-free relay contacts are added to the overall system. All relay contacts can be freely assigned to the incoming measuring signals and can therefore be used, for example, for limit value-related control concepts or measured value-related messages.Advantages:individual implementation of:
alarm message based on received measured values and/or status messages
switching contacts for simple valve control
compact design for top hat rail mounting
when using several modules only one power supply is necessary
modular expandable according to process requirements
By using these NeoTec Slave relay modules, potential-free relay contacts are added to the overall system. All relay contacts can be freely assigned to the incoming measuring signals and can therefore be used, for example, for limit value-related control concepts or measured value-related messages.Advantages:individual implementation of:
alarm message based on received measured values and/or status messages
switching contacts for simple valve control
compact design for top hat rail mounting
when using several modules only one power supply is necessary
modular expandable according to process requirements
The NeoTec Slave RS232 enables the integration of further devices. For example, the Testomat® LAB/Modul and Testomat® EVO TH series. The software of the NeoTecMaster® is already pre-parameterized ex works for the device types named here and immediately enables the reception of measurement results and status messages as well as their further processing.Advantages:compact design for top hat rail mounting
when using several modules only one power supply is necessary
can be added module by module up to max. 7 pieces
NeoTec Slave function module 1:
without
|
NeoTec Slave function module 2:
without
|
NeoTec Slave function module 3:
without
|
Number of parameters to be measured, up to:
4
Our 4- or 8- channel system allows the processing of up to four or eight measurement signals. For this purpose, 4-20 mA/ RS232 as well as Modbus RTU are available as signal inputs. Based on the received data a visualization as well as a trend display takes place. Through modular addition of optional modules (slaves) the realization of popular control concepts is possible.Advantages:Simple operation
Integration of the Testomat® device world
Integration into the existing control cabinet, alternatively we offer our NeoTecMaster® housingModular function range expandable by NeoTec slave modules (measure, control, control)Available as installation variant or structure variant
The housing for holding the master or display unit as well as up to 6 function modules incl. optimized cable routing for connecting the individual components & PG glands for connecting external cables (e.g. for Ethernet, sensors and measurement technology). The advantages at a glance: Increase of the protection class to IP 66 and thus protection of the components against damage by environmental conditions. Optimized access for the cabling of the connected components.
A ORP sensor from the NeoTec Select Standard product range with 4 - 20 mA module permanently encapsulated in the sensor body.Advantages:Preconfigured for NeoTecMaster®
Industry standard
Can be used as immersion probe
The ORP sensor from the NeoTec Select Standard product range with Modbus module permanently encapsulated in the sensor body.Advantages:Preconfigured for NeoTecMaster®
Industry standard
Can be used as immersion probe
A pH sensor from the NeoTec Select Standard product range with 4 - 20 mA module permanently encapsulated in the sensor body.Advantages:Preconfigured for NeoTecMaster®
Industry standard
Can be used as immersion probe
A pH sensor from the NeoTec Select Standard product range with Modbus modul encapsulated in the sensor body.Advantages:Preconfigured for NeoTecMaster®
Industry standard
Can be used as immersion probe
